Hit Shapes

Non-rectangular UI regions in s&box

Hit Shapes wraps a shape resolver in a state machine that turns whole-panel mouse events into per-slot OnSlotEnter / OnSlotLeave / OnSlotClick callbacks.

Depends only on Vector2 and MousePanelEvent


Quick start example:
  1. Download the library
  2. Make a screen panel GameObject
  3. Add UI Panel --> Razor Hit Shape Demo
  4. Link camera to the Screen Panel
  5. Hit play

Built-in shapes


 Radial(slots, innerRatio?, outerRatio?)  - Wheel of equal wedges  - 0..slots-1, clockwise from 12 o'clock
RectGrid(cols, rows)  - Uniform grid  - row-major, top-left = 0
Polygon(verts)  - One polygon, unit coords  - always 0 if inside
Polygons(polys)  - Many polygons  - index of first containing polygon
Custom(slotCount, nativeSize, fn)  - Resolver de-scaled to a fixed pixel frame  - whatever you return
CustomRaw(slotCount, fn)  - Resolver receives raw engine-frame coords  - whatever you return
Union(a, b)  - A's slots, then B's offset by A.SlotCount  - A wins on overlap
Intersect(a, b)  - A's slot, only where B also resolves  - A's slot count
Difference(a, b)  - A's slot, where B does NOT resolve  - A's slot count

Media (3)

Hit Shapes - Thumbnail 1 Hit Shapes - Thumbnail 2 Hit Shapes - Thumbnail 3
No usage statistics available
This package may be new or not widely used yet. Usage data becomes available as more users install and play with the package.
Package ID: xaz.hit_shapes
Created: 2026-05-25 06:14 UTC
Updated: 2026-06-06 21:14 UTC
Type: library
Public: Yes
Version: 276866
files: 28
Size: 0.1 MB
Engine Version: 25
Asset Version ID: 276866
Version Created: 2026-06-06 21:14 UTC
Hash: 3393247542790211050
Manifest: Open manifest
Compiler: Sandbox, SANDBOX, 1701;1702;1591;, , , , Release, Array, Array, Array, Array
Resources:
Code Package References:
new_releases Latest Update Jun 6, 2026
Small update
276866 Jun 6, 2026
Small update
270209 May 25, 2026
fix ui
270205 May 25, 2026
added example
270198 May 25, 2026
initial commit
